Used Komatsu 110-8Excavator

Reading: 29

📌 Overview

The Komatsu PC110-8 is a midi-class hydraulic excavator weighing approximately 11 tonnes, launched as part of Komatsu's -8 generation (released around 2019–2020). It is designed for versatility in utility work, landscaping, road construction, and small-to-medium earthmoving projects. It replaces the previous PC110-7 model with significant upgrades in efficiency, comfort, and technology.

🔧 Engine & Emissions

Specification	Details
Engine Model	Komatsu SAA4D95LE-5
Type	4-cylinder, turbocharged, intercooled diesel
Displacement	3.269 liters
Net Power	~59.6 kW (80 hp) @ 2,000 rpm
Emission Standard	EPA Tier 4 Final / EU Stage V (no DEF/AdBlue required — uses DOC + DPF system)
Fuel Tank Capacity	~170 liters (44.9 gal)

✅ The -8 generation uses selective catalytic reduction (SCR)-free aftertreatment, reducing maintenance complexity.

⚖️ Dimensions & Weight

Parameter	Specification
Operating Weight	10,800 – 11,000 kg (23,810 – 24,250 lbs)
Transport Length	~7,420 mm (24'4")
Transport Width	~2,490 mm (8'2")
Transport Height	~2,780 mm (9'1")
Ground Clearance	~420 mm (16.5")
Track Width	Adjustable: 1,800 / 2,200 / 2,500 mm
Track Shoe Width	500 mm (20") or 600 mm (24") options

🏗️ Performance (Working Range)

Parameter	Specification
Max Digging Depth	~5,440 mm (17'10")
Max Digging Reach	~7,530 mm (24'8")
Max Dumping Height	~4,880 mm (16'0")
Max Dumping Reach	~4,450 mm (14'7")
Max Digging Force (Boom)	~48.1 kN (10,810 lbf)
Max Digging Force (Arm)	~35.3 kN (7,940 lbf)
Bucket Capacity (Std)	0.3 – 0.5 m³ (0.4 – 0.65 yd³)
Swing Speed	~10.5 rpm
Travel Speed (H/L)	5.0 / 3.2 km/h (3.1 / 2.0 mph)

🖥️ Key Technology Features (Generation -8)

Feature	Description
🧠 iMC (Intelligent Machine Control)	GPS/GNSS-ready for 3D grading, 2D/3D guidance — reduces rework and improves accuracy
⚡ EPOS (Electronic Power Optimized System)	Hydraulic system that auto-matches engine output to demand, saving up to 10–15% fuel vs. previous gen
📡 Komtrax	Remote machine monitoring & telematics (location, hours, diagnostics, fuel usage)
🪟 Redesigned Cab	Larger glass area, 30% better visibility, low-vibration suspension seat, climate-controlled A/C
🎮 New Control Levers	Ergonomic joystick-style levers with reduced effort by ~30%
🔧 Easy Maintenance Access	Ground-level check points, side-opening panels, centralized grease points
📹 Rearview Camera	Standard on most configurations
🔌 Auxiliary Hydraulics	Multiple circuits for attachments (breakers, grapples, augers)

🛠️ Available Configurations

Configuration	Description
Standard Boom	General purpose digging
Long Reach (LR)	Extended reach for demolition / deep digging
High Dump	Elevated dump for truck loading
Dozer Blade (D)	Fitted with dozer blade for grading/leveling
Pipeline / Narrow	Narrow undercarriage for tight spaces
Cab / ROPS/FOPS	Enclosed air-conditioned cab or open ROPS canopy

💰 Approximate Pricing (2024 Estimates)

Region	Price Range (USD)
🇺🇸 North America	$115,000 – $145,000 (varies by config & attachments)
🇪🇺 Europe	€100,000 – €130,000
🌏 Asia-Pacific	$100,000 – $130,000

Prices vary significantly based on options (iMC, cab type, auxiliary lines, etc.)

📊 Competitors

Machine	Class	Power	Weight
Cat 311 / 312	11–12 ton	74–84 hp	11,200–12,500 kg
John Deere 110G LC	10–11 ton	74 hp	10,800 kg
Hitachi ZX110LC-6	11 ton	74 hp	10,900 kg
Volvo ECR110E	11 ton	74 hp	11,000 kg
Kobelco SK115SR-8	11.5 ton	74 hp	11,700 kg

✅ Strengths (Pros)

✅	Detail
&Fuel Efficient**	EPOS system delivers class-leading fuel economy
🧠 Tech-Ready	iMC-ready out of the box — future-proof for automation
💺 Operator Comfort	Best-in-class cab comfort for this size
🔧 Low Maintenance	SCR-free emissions = no AdBlue, simpler DPF regeneration
📡 Komtrax	Excellent telematics & fleet management
🔄 Resale Value	Komatsu holds strong residual values globally

⚠️ Limitations (Cons)

❌	Detail
📦 Limited Bucket Size	Max ~0.5 m³ — not ideal for large-scale production
💰 Higher Purchase Price	Premium pricing vs. some Chinese competitors
🔧 Parts Cost	OEM parts can be expensive in some regions
📏 Not for Heavy Mining	Better suited for utility/construction, not quarry work

🏁 Summary

Category	Rating (out of 5)
⚡ Power & Performance	⭐⭐⭐⭐
⛽ Fuel Efficiency	⭐⭐⭐⭐⭐
💺 Operator Comfort	⭐⭐⭐⭐⭐
🧠 Technology	⭐⭐⭐⭐⭐
💰 Value for Money	⭐⭐⭐⭐
🔧 Serviceability	⭐⭐⭐⭐

🎯 Bottom Line:
The Komatsu PC110-8 is one of the most technologically advanced midi excavators on the market. It excels in fuel efficiency, operator comfort, and smart machine readiness (iMC). It's the ideal choice for contractors who want precision, productivity, and lower operating costs in the 10–11 tonne class.
