Used Volvo 480Excavator

Reading: 16

The Volvo EC480E is a 48-tonne class crawler excavator, one of the largest and most powerful models in Volvo Construction Equipment's E-Series lineup. It is designed for heavy-duty applications such as large-scale mining, quarrying, demolition, and major infrastructure projects.

📋 1. GENERAL OVERVIEW

Parameter	Specification
Model	Volvo EC480E (Stage V / Tier 4 Final)
Class	Large Crawler Excavator (48-tonne)
Manufacturer	Volvo Construction Equipment (Sweden)
Production	Current generation (2020–present)
Application	Mining, quarrying, large earthmoving, demolition, heavy construction

⚙️ 2. ENGINE & POWERTRAIN

Specification	Detail
Engine Model	Volvo D13 TC (Stage V / Tier 4 Final)
Type	6-cylinder, turbocharged, intercooled diesel
Displacement	12.8 liters
Rated Power	330 kW (443 hp) @ 1,800 rpm
Max Torque	2,200 Nm @ 1,200 rpm
Emission Standard	EU Stage V / EPA Tier 4 Final (with SCR + DPF)
Fuel Tank Capacity	~750 liters
DEF Tank	~40 liters (for SCR system)

✅ The D13 engine is known for its high torque at low RPM, making it ideal for heavy digging and tough conditions.

📐 3. DIMENSIONS & WEIGHT

Parameter	Value
Operating Weight	~48,000 – 49,000 kg (varies by configuration)
Transport Length	~11,390 mm
Transport Width	3,190 mm
Transport Height	3,340 mm
Ground Clearance	470 mm
Track Width	600 mm (standard) / 700 mm (wide)
Track Shoe Length	5,600 mm
Shoe Width	600 mm

🔧 4. PERFORMANCE & DIGGING CAPACITY

Parameter	Value
Max Digging Depth	7,390 mm
Max Digging Reach	11,130 mm
Max Vertical Wall Dig	7,070 mm
Max Dumping Height	7,350 mm
Max Digging Force (Boom/Arm)	245 kN
Max Breakout Force	200 kN
Bucket Capacity (Standard)	1.7 – 2.2 m³ (range: 0.6 – 2.5 m³)
Hydraulic System Pressure	350 bar (5,075 psi)
Hydraulic Flow	2 × 370 L/min

🏠 5. CAB & OPERATOR COMFORT (PRO Cabin)

The EC480E features Volvo's award-winning PRO Cabin, designed for maximum comfort during long working hours:

Feature	Detail
🪑 Suspension Seat	Air-suspended, heated, with armrests
🖥️ Display	9-inch touchscreen (Volvo Co-Pilot interface)
❄️ Climate Control	Fully automatic A/C with dual-zone
🔊 Noise Level	~73 dB(A) — one of the quietest in class
💡 Lighting	Full LED work lights
📹 Cameras	Rear-view camera, blind-spot cameras
🔇 Vibration	Extremely low vibration levels
📡 Connectivity	Volvo CareTrack telematics built-in

🤖 6. SMART TECHNOLOGY & FEATURES

Technology	Description
🛰️ Volvo Co-Pilot	3D machine control system — allows operators to dig to exact design grades using GPS/total station
📊 CareTrack	Real-time telematics — tracks fuel consumption, location, idle time, diagnostics
🌱 ECO Mode	Automatically adjusts engine speed to match hydraulic demand — saves up to 15% fuel
🔄 Auto Idle Shutdown	Engine automatically reduces RPM when not working
📱 Volvo Active Control (VAC)	Available — helps less-experienced operators work more efficiently
⚡ Boom Slower	Smoother boom lowering for precision work
🔧 Auto Swing Stop (ASS)	Prevents swing when not needed — increases safety & efficiency

🛡️ 7. SAFETY

Safety Feature	Detail
✅ ROPS/FOPS	Certified rollover & falling object protection
✅ Auto-lubrication	Reduces maintenance & prevents wear
✅ Emergency Stop	Multiple emergency stop points
✅ Speed Limiter	Optional transport speed limiter
✅ Blind Spot Detection	Camera-based system

🔩 8. HYDRAULIC ATTACHMENTS & VERSATILITY

The EC480E supports a wide range of attachments via the Volvo Smart Hitch quick coupler system:

Attachment	Application
🔨 Hydraulic Breaker	Rock breaking, demolition
🪓 Hydraulic Grapple	Scrap handling, sorting
🦷 Bucket (various sizes)	General digging
🔧 Thumb	Precision handling
🔄 Tiltrotator	360° rotation of attachment
🔩 Pulverizer	Concrete crushing
🪣 Orange Peel Grab	Scrap metal handling
❄️ Ripper	Hard ground breaking

🆚 9. COMPARISON WITH COMPETITORS

Model	Weight	Power	Max Dig Depth
Volvo EC480E	~48,000 kg	443 hp	7,390 mm
CAT 349 GC	~49,000 kg	429 hp	7,610 mm
Komatsu PC490LC-11	~48,700 kg	434 hp	7,570 mm
Hitachi ZX490LCH-7	~48,400 kg	435 hp	7,550 mm
Doosan DX490LC-7	~48,000 kg	438 hp	7,450 mm

🏆 The EC480E is widely regarded as having best-in-class fuel efficiency, lowest noise levels, and best operator comfort.

💰 10. APPROXIMATE PRICING

Region	Approximate Price (USD)
🇺🇸 North America	$450,000 – $550,000
🇪🇺 Europe	€400,000 – €500,000
🌏 Asia	$380,000 – $480,000

(Prices vary based on configuration, attachments, and market)

✅ SUMMARY — WHY CHOOSE VOLVO EC480E?

Strength	Detail
💪 Power	443 hp D13 engine — class-leading torque
🌱 Fuel Efficiency	ECO mode saves up to 15% fuel
🪑 Comfort	PRO cabin — best operator experience in class
🔇 Quiet	~73 dB(A) — quietest large excavator
🤖 Technology	Co-Pilot 3D, CareTrack, VAC
🔧 Reliability	Volvo's legendary build quality & dealer network
🛡️ Safety	ROPS/FOPS, cameras, auto-shutdown

The Volvo EC480E is truly a flagship machine — built for operators and contractors who demand maximum productivity, comfort, and technology in the toughest working conditions. 🇸🇪🏗️
