Used Xcmg 60 Excavator

Reading: 28

XCMG (Xuzhou Construction Machinery Group) is one of the world's top 3 construction machinery manufacturers. Their 6-ton class excavators are among the best-selling mini/small excavators globally. The main models include:

Model	Version
XE60DA	Latest upgraded version (most popular)
XE60D	Standard version
XE60GA	Compact/crawler variant
XE60D PRO	Enhanced version

📐 1. KEY SPECIFICATIONS (XE60DA as reference)

Parameter	Specification
Operating Weight	5,800 – 6,000 kg
Engine	Yanmar 4TNV98-ZPLYS / XCMG Cummins
Engine Power	40.3 – 45 HP (29.6 kW)
Rated Speed	2,200 rpm
Max Digging Depth	3,720 – 3,990 mm
Max Digging Radius	6,180 – 6,340 mm
Max Dumping Height	4,230 – 4,520 mm
Bucket Capacity	0.16 – 0.23 m³ (standard)
Travel Speed	2.7 – 4.5 km/h
Gradeability	35° (70%)
Ground Pressure	0.032 – 0.034 MPa
Fuel Tank	100 – 120 L
Hydraulic System	Load-sensing, axial piston pump

🔧 2. ENGINE & POWER SYSTEM

Feature	Details
Engine Brand	Yanmar (Japan) — most common / XCMG proprietary
Emission Standard	China III / Euro Stage V (export models)
Fuel Type	Diesel
Cooling	Water-cooled with radiator
Turbocharged	✅ Yes
After-treatment	DOC + DPF (for EU markets)

✅ The Yanmar engine is known for fuel efficiency, reliability, and low noise — a key selling point.

🏗️ 3. HYDRAULIC SYSTEM

Feature	Details
Pump Type	Double axial piston, variable displacement
System Pressure	34.3 MPa (main) / 23.5 MPa (pilot)
Flow Rate	2 × 55 L/min (combined)
Control Mode	Electro-hydraulic proportional joystick
Attachment Options	✅ Breaker (hammer), ✅ Auger, ✅ Thumb, ✅ Ripper, ✅ Grapple, ✅ Quick coupler

🛡️ 4. STRUCTURE & UNDERCARRIAGE

Component	Details
Boom & Arm	High-strength steel, box-section, finite-element optimized
Track Width	Adjustable: 1,200 – 1,500 mm
Track Shoe	400 mm wide, triple-grouser (optional)
Rollers	4 upper + 1 lower per side
Cab	ROPS/FOPS certified, spacious, with AC (optional)
Seat	Suspension seat with armrest

🖥️ 5. OPERATOR COMFORT & SMART FEATURES (XE60DA)

Feature	Description
🎛️ LCD Monitor	Real-time engine data, fault codes, fuel consumption
📡 GPS/Telematics	XCMG "X-GATE" remote monitoring system
❄️ Air Conditioning	Optional, full-sealed cab
🔇 Noise Level	~68 dB(A) — very quiet for its class
🛋️ Suspension Seat	Reduces operator fatigue
💡 LED Work Lights	Front & rear
🔄 One-Touch Auto-Idle	Saves fuel during pauses
🛡️ Anti-Theft System	Engine immobilizer

💰 6. PRICING (Approximate, 2024)

Region	Price Range (USD)
🇨🇳 China	$35,000 – $45,000
🌏 Southeast Asia	$40,000 – $50,000
🌍 Europe/Australia	$55,000 – $70,000
🇺🇸 North America	$60,000 – $75,000

💡 XCMG offers strong price competitiveness vs. Komatsu PC60, Kubota KX060, CAT 306, and Doosan DX60.

✅ 7. ADVANTAGES

✅ Pro	Explanation
💰 Cost-effective	20-30% cheaper than Japanese brands
🔧 Easy maintenance	Wide parts availability globally
🌐 Global dealer network	190+ countries, strong after-sales
💪 Durable	Designed for harsh conditions (mining, farms)
🔌 Versatile	Works with 10+ attachments
📉 Low fuel consumption	~4-5 L/hour (idle/light work)

⚠️ 8. CONSIDERATIONS

⚠️ Con	Explanation
🔄 Resale value	Slightly lower than Komatsu/CAT
🛠️ Parts quality variance	Some non-genuine parts in developing markets
📊 Finish quality	Good but not quite Japanese-level precision

🎯 9. TYPICAL APPLICATIONS

Application	Suitability
🏡 Residential construction	⭐⭐⭐⭐⭐
🌾 Farming & landscaping	⭐⭐⭐⭐⭐
🛣️ Road & pipeline work	⭐⭐⭐⭐
🏚️ Demolition (with breaker)	⭐⭐⭐⭐
🏔️ Mining (narrow space)	⭐⭐⭐⭐
🏗️ Municipal/utility work	⭐⭐⭐⭐⭐

📊 10. COMPARISON WITH COMPETITORS

Spec	XCMG XE60DA	Komatsu PC60-8	Kubota KX060-4	CAT 306 E2
Power	45 HP	44.7 HP	40 HP	44 HP
Weight	5,950 kg	6,120 kg	5,830 kg	6,150 kg
Dig Depth	3,990 mm	3,930 mm	3,730 mm	4,010 mm
Price	💰💰	💰💰💰	💰💰💰	💰💰💰💰
Warranty	2 yrs / 2000h	2 yrs / 2000h	3 yrs / 2000h	2 yrs / 2000h

🏆 SUMMARY

The XCMG XE60DA is arguably the best value-for-money 6-ton excavator in the world right now. It combines Japanese-grade Yanmar engine reliability with Chinese cost efficiency, backed by XCMG's massive global service network. It's ideal for contractors, farmers, and rental companies looking for a dependable, affordable mini excavator.
