Used Liugong 856Loader

Reading: 34

📋 Overview

Item	Details
Model	CLG856 (also called LiuGong 856)
Manufacturer	Guangxi LiuGong Machinery Co., Ltd. (柳工)
Class	5-Ton Wheel Loader
Rated Bucket Capacity	3.0 m³ (standard)
Country of Origin	China 🇨🇳
Application	Mining, construction, aggregates, landscaping, loading trucks

🔧 Engine & Power System

Specification	Detail
Engine Brand	Weichai (潍柴) WP10G / WD10G Series
Engine Model	WD10G220E21 (or WP10G220E22)
Type	6-cylinder, Turbocharged, Intercooled Diesel
Emission Standard	China III / Euro III (upgradable to China IV)
Rated Power	~162 kW (217 HP) @ 2,000 rpm
Max Torque	~850 N·m @ 1,400 rpm
Fuel Tank Capacity	~300 L

✅ The Weichai engine is known for reliability, fuel efficiency, and strong low-end torque — perfect for heavy loading operations.

⚙️ Transmission & Drive System

Specification	Detail
Transmission Type	Power Shift ( planetary gear )
Transmission Brand	ZF or LiuGong proprietary
Gears	2 Forward / 2 Reverse
Torque Converter	Single-stage, 3-element
Drive Type	4WD (Full-time)
Differential Lock	✅ Rear axle differential lock (optional front)
Steering	Articulated frame steering
Max Speed	~35 km/h (forward) / ~14 km/h (reverse)
Gradeability	~30° (58%)

📐 Dimensions & Weights

Specification	Detail
Operating Weight	~17,000 – 17,500 kg
Overall Length (w/ bucket)	~8,250 mm
Overall Width	~3,050 mm
Overall Height (to cab top)	~3,300 mm
Wheelbase	~3,200 mm
Ground Clearance	~450 mm
Tire Size	23.5-25 (16-ply E-3/L-3 pattern)
Turning Radius (outer)	~6,800 mm

💪 Performance (Hydraulic System)

Specification	Detail
Hydraulic Pump Type	Gear pump (double pump, priority steering)
System Pressure	16 – 17.5 MPa
Hydraulic Flow	~190 L/min
Max Dumping Height	~3,100 – 3,200 mm
Max Dump Reach	~1,000 – 1,100 mm
Max Breakout Force	~170 – 180 kN
Max Tractive Force	~160 – 170 kN
Lift Time (empty to full)	~6.0 seconds
Dig Time (full to ground)	~4.5 seconds
Cycle Time	~10 – 12 seconds

🛋️ Cab & Operator Comfort

Feature	Detail
Cab Type	ROPS/FOPS certified, fully enclosed
Seat	Air-suspension, adjustable, heated (optional)
Air Conditioning	✅ Standard
Heating	✅ Standard
Control	Joystick (optional) / Lever
Display	LCD monitor with engine diagnostics
Noise Level	≤ 78 dB(A)
Reverse Camera	✅ Standard
Work Lights	Front & rear LED work lights
ROPS/FOPS	✅ Certified (Roll-over & Falling Object Protection)

🔩 Attachments & Versatility

The CLG856 is a highly versatile machine with quick-coupler compatibility:

Attachment	Application
🪣 Standard Bucket (3.0 m³)	General loading
🥄 Rock Bucket	Mining, quarrying
🪵 Log Grapple / Forks	Logging, pipe handling
🧹 Snow Blade	Snow removal
🔨 Pallet Forks	Pallet handling
🪤 Sweeper	Road cleaning
🔄 Snow Tire Chains	Winter operations

🌟 Key Advantages

✅ Advantage	Explanation
💪 Strong & Powerful	Weichai 217HP engine delivers excellent breakout & tractive force
&Fuel Efficient**	Optimized engine + hydraulic system saves 10-15% fuel vs competitors
🛠️ Easy Maintenance	Ground-level service points, wide-opening hood
💰 Cost-Effective	Lower purchase price than CAT/Komatsu (~40-50% savings)
🌐 Wide Parts Availability	LiuGong has 300+ dealers worldwide
🔧 Durable	Heavy-duty axles, reinforced frame, long service life
📈 Resale Value	Strong in secondary markets (Africa, SE Asia, S. America)

🆚 Comparison with Competitors

Spec	LiuGong 856	CAT 950	SDLG 956	XCMG LW500
Power	217 HP	350 HP	220 HP	220 HP
Bucket	3.0 m³	3.2 m³	3.0 m³	3.0 m³
Weight	17.0 t	20.5 t	17.2 t	17.0 t
Price (approx.)	$85K-$100K	$250K+	$90K-$105K	$95K-$110K
Best For	Value & Medium Duty	Heavy Mining	Value	Value

🏆 LiuGong 856 offers the best price-to-performance ratio in the 5-ton class.

🌍 Market Presence

Region	Popularity
🇨🇳 China	⭐⭐⭐⭐⭐ (Domestic leader)
🌍 Southeast Asia	⭐⭐⭐⭐⭐
🌍 Africa	⭐⭐⭐⭐⭐ (Very popular)
🌍 Middle East	⭐⭐⭐⭐
🌍 South America	⭐⭐⭐⭐
🌍 Europe/N.America	⭐⭐⭐ (Growing)

📊 Summary

Category	Rating
Power	⭐⭐⭐⭐
Durability	⭐⭐⭐⭐⭐
Comfort	⭐⭐⭐⭐
Fuel Efficiency	⭐⭐⭐⭐
Value for Money	⭐⭐⭐⭐⭐
After-Sales	⭐⭐⭐⭐

🎯 Bottom Line

The LiuGong CLG856 is one of the best-selling 5-ton wheel loaders in the world, especially in developing markets. It combines a powerful Weichai engine, robust construction, modern cab comfort, and an unbeatable price point — making it the go-to choice for contractors who want CAT/Komatsu performance at a fraction of the cost.

Would you like more details on pricing, spare parts, or comparisons with a specific model? 😊
